Trawlfloats without holes

Available on request

Trawlfloats without holes in 5 sizes.

Trawlfloats without holes — manufacturer dimension drawing

Specifications

Diameter range9–14 inch
Sizes tabulated5

Missing a spec? It's available on request — send us your requirement.

Sizes & part numbers

5 sizes available. Quote by part number, or send us the load and we'll size it.

Trawlfloats without holes — sizes and part numbers
Part no.Dia.(inch)Working depthColorVolume(liter)Weight(gr)Buoyancy(gr)
NP09-1800-NG91800Green6.522004030
NP10-2100-NG102100Green8.034605070
NP10-3800-NG103800Green8.037505120
NP14-0800-NM14800Red25642021000
NP14-1500-NM141500Red25820516900

Scroll the table sideways for all 7 columns.
