Hampidjan Canada

Inflatable low resistance marker buoys

Available on request

Inflatable low resistance marker buoys in 4 sizes.

Inflatable low resistance marker buoys — manufacturer dimension drawing

Specifications

Diameter range240–415 mm
Sizes tabulated4

Missing a spec? It's available on request — send us your requirement.

Sizes & part numbers

4 sizes available. Quote by part number, or send us the load and we'll size it.

Inflatable low resistance marker buoys — sizes and part numbers
Part no.Dia.(mm)Length.(mm)Buoyancy gross(kg)Eye diam.(mm)Circumf.(mm)Weight(kg/pcs)
LR-124047013287501.2
LR-231060032289702.1
LR-3360730532811303.1
LR-4415930842813005.1

Scroll the table sideways for all 7 columns.

  • *) LR-4 Supplied as standard with stainless steel-eye insert.
  • Standard colours: ROPE HOLD = Black / BUOY = White, Red(orange) or Yellow
  • Optional colours: BUOY = Black, Grey, Blue, Navy blue, Dark Red or Green
